Nextcloud Deployment Recommendations

What is the best way to install and maintain Nextcloud? The answer to that is “it depends” because every Nextcloud customer has their own particular needs and IT infrastructure. Nextcloud and the LAMP stack are highly-configurable, so we will present three typical scenarios and make best-practice recommendations for both software and hardware.

General Recommendations

Note

Whatever the size of your organization, always keep one thing in mind: the amount of data stored in Nextcloud will only grow. Plan ahead.

Consider setting up a scale-out deployment, or using Federated Cloud Sharing to keep individual Nextcloud instances to a manageable size.

  • Operating system: Linux.
  • Web server: Apache 2.4.
  • Database: MySQL/MariaDB.
  • PHP 5.5+. PHP 5.4 is the minimum supported version; note that it reached end-of-life in September 2015 and is no longer supported by the PHP team. Some Linux vendors, such as Red Hat, still support PHP 5.4. 5.6+ is recommended. mod_php is the recommended Apache module because it provides the best performance.

Small Workgroups or Departments

  • Number of users

    Up to 150 users.

  • Storage size

    100 GB to 10TB.

  • High availability level

    Zero-downtime backups via Btrfs snapshots, component failure leads to interruption of service. Alternate backup scheme on other filesystems: nightly backups with service interruption.

Mid-sized Enterprises

  • Number of users

    150 to 1,000 users.

  • Storage size

    Up to 200TB.

  • High availability level

    Every component is fully redundant and can fail without service interruption. Backups without service interruption

Recommended System Requirements

2 to 4 application servers.

A cluster of two database servers.

Storage on an NFS server.

Authentication via an existing LDAP or Active Directory server.

Network diagram for mid-sized enterprise.
  • Components
    • 2 to 4 application servers with 4 sockets and 32GB RAM.
    • 2 DB servers with 4 sockets and 64GB RAM.
    • 1 HAproxy load balancer with 2 sockets and 16GB RAM.
    • NFS storage server as needed.
  • Operating system

    Enterprise grade Linux distribution with full support from OS vendor. Red Hat Enterprise Linux or SUSE Linux Enterprise Server 12 are recommended.

  • SSL Configuration

    The SSL termination is done in the HAProxy load balancer. A standard SSL certificate is needed, installed according to the HAProxy documentation.

  • Load Balancer

    HAProxy running on a dedicated server in front of the application servers. Sticky session needs to be used because of local session management on the application servers.

  • Database

    MySQL/MariaDB Galera cluster with master-master replication.

  • Backup

    Minimum daily backup without downtime. All MySQL/MariaDB statements should be replicated to a backup MySQL/MariaDB slave instance.

    • Create a snapshot on the NFS storage server.
    • At the same time stop the MySQL replication.
    • Create a MySQL dump of the backup slave.
    • Push the NFS snapshot to the backup.
    • Push the MySQL dump to the backup.
    • Delete the NFS snapshot.
    • Restart MySQL replication.
  • Authentication

    User authentication via one or several LDAP or Active Directory servers. (See User Authentication with LDAP for information on configuring Nextcloud to use LDAP and AD.)

  • LDAP

    Read-only slaves should be deployed on every application server for optimal scalability

  • Session Management

    Session management on the application server. PHP sessions are stored in a tmpfs mounted at the operating system-specific session storage location. You can find out where that is by running grep -R 'session.save_path' /etc/php5 and then add it to the /etc/fstab file, for example: echo "tmpfs /var/lib/php5/pool-www tmpfs defaults,noatime,mode=1777 0 0" >> /etc/fstab.

  • Memory Caching

    A memcache speeds up server performance, and Nextcloud supports four memcaches; refer to Configuring Memory Caching for information on selecting and configuring a memcache.

  • Storage

    Use an off-the-shelf NFS solution, such as IBM Elastic Storage or RedHat Ceph.

  • Nextcloud Edition

    Enterprise Edition. (See Nextcloud Server or Enterprise Edition for comparisons of the Nextcloud editions.)

Large Enterprises and Service Providers

  • Number of users

    5,000 to >100,000 users.

  • Storage size

    Up to 1 petabyte.

  • High availabily level

    Every component is fully redundant and can fail without service interruption. Backups without service interruption

Recommended System Requirements

4 to 20 application/Web servers.

A cluster of two or more database servers.

Storage is an NFS server, or an object store that is S3 compatible.

Cloud federation for a distributed setup over several data centers.

Authentication via an existing LDAP or Active Directory server, or SAML.

Network diagram for large enterprise.
  • Components
    • 4 to 20 application servers with 4 sockets and 64GB RAM.
    • 4 DB servers with 4 sockets and 128GB RAM
    • 2 Hardware load balancer, for example BIG IP from F5
    • NFS storage server as needed.
  • Operating system

    RHEL 7 with latest service packs.

  • SSL Configuration

    The SSL termination is done in the load balancer. A standard SSL certificate is needed, installed according to the load balancer documentation.

  • Load Balancer

    A redundant hardware load-balancer with heartbeat, for example F5 Big-IP. This runs two load balancers in front of the application servers.

  • Database

    MySQL/MariaDB Galera Cluster with 4x master – master replication.

  • Backup

    Minimum daily backup without downtime. All MySQL/MariaDB statements should be replicated to a backup MySQL/MariaDB slave instance.

    • Create a snapshot on the NFS storage server.
    • At the same time stop the MySQL replication.
    • Create a MySQL dump of the backup slave.
    • Push the NFS snapshot to the backup.
    • Push the MySQL dump to the backup.
    • Delete the NFS snapshot.
    • Restart MySQL replication.
  • Authentication

    User authentication via one or several LDAP or Active Directory servers, or SAML/Shibboleth. (See User Authentication with LDAP.)

  • LDAP

    Read-only slaves should be deployed on every application server for optimal scalability.

  • Session Management

    Redis should be used for the session management storage.

  • Caching

    Redis for distributed in-memory caching (see Configuring Memory Caching).

  • Storage

    An off-the-shelf NFS solution should be used. Examples are IBM Elastic Storage or RedHAT Ceph. Optionally, an S3 compatible object store can also be used.

  • Nextcloud Edition

    Enterprise Edition. (See Nextcloud Server or Enterprise Edition for comparisons of the Nextcloud editions.)

Hardware Considerations

  • Solid-state drives (SSDs) for I/O.
  • Separate hard disks for storage and database, SSDs for databases.
  • Multiple network interfaces to distribute server synchronisation and backend traffic across multiple subnets.

Single Machine / Scale-Up Deployment

The single-machine deployment is widely used in the community.

Pros:

  • Easy setup: no session storage daemon, use tmpfs and memory caching to enhance performance, local storage.
  • No network latency to consider.
  • To scale buy a bigger CPU, more memory, larger hard drive, or additional hard drives.

Cons:

  • Fewer high availability options.
  • The amount of data in Nextcloud tends to continually grow. Eventually a single machine will not scale; I/O performance decreases and becomes a bottleneck with multiple up- and downloads, even with solid-state drives.

Scale-Out Deployment

Provider setup:

  • DNS round robin to HAProxy servers (2-n, SSL offloading, cache static resources)
  • Least load to Apache servers (2-n)
  • Memcached/Redis for shared session storage (2-n)
  • Database cluster with single Master, multiple slaves and proxy to split requests accordingly (2-n)
  • GPFS or Ceph via phprados (2-n, 3 to be safe, Ceph 10+ nodes to see speed benefits under load)

Pros:

  • Components can be scaled as needed.
  • High availability.
  • Test migrations easier.

Cons:

  • More complicated to setup.
  • Network becomes the bottleneck (10GB Ethernet recommended).
  • Currently DB filecache table will grow rapidly, making migrations painful in case the table is altered.

What About Nginx / PHP-FPM?

Could be used instead of HAproxy as the load balancer. But on uploads stores the whole file on disk before handing it over to PHP-FPM.

A Single Master DB is Single Point of Failure, Does Not Scale

When master fails another slave can become master. However, the increased complexity carries some risks: Multi-master has the risk of split brain, and deadlocks. Nextcloud tries to solve the problem of deadlocks with high-level file locking.

Software Considerations

Operating System

We are dependent on distributions that offer an easy way to install the various components in up-to-date versions. Nextcloud has a partnership with RedHat and SUSE for customers who need commercial support. Canonical, the parent company of Ubuntu Linux, also offers enterprise service and support. Debian and Ubuntu are free of cost, and include newer software packages. CentOS is the community-supported free-of-cost Red Hat Enterprise Linux clone. openSUSE is community-supported, and includes many of the same system administration tools as SUSE Linux Enterprise Server.

Web server

Taking Apache and Nginx as the contenders, Apache with mod_php is currently the best option, as Nginx does not support all features necessary for enterprise deployments. Mod_php is recommended instead of PHP_FPM, because in scale-out deployments separate PHP pools are simply not necessary.

Relational Database

More often than not the customer already has an opinion on what database to use. In general, the recommendation is to use what their database administrator is most familiar with. Taking into account what we are seeing at customer deployments, we recommend MySQL/MariaDB in a master-slave deployment with a MySQL proxy in front of them to send updates to master, and selects to the slave(s).

The second best option is PostgreSQL (alter table does not lock table, which makes migration less painful) although we have yet to find a customer who uses a master-slave setup.

What about the other DBMS?

  • Sqlite is adequate for simple testing, and for low-load single-user deployments. It is not adequate for production systems.
  • Microsoft SQL Server is not a supported option.
  • Oracle DB is the de facto standard at large enterprises and is fully supported with Nextcloud Enterprise Edition only.

File Storage

While many customers are starting with NFS, sooner or later that requires scale-out storage. Currently the options are GPFS or GlusterFS, or an object store protocol like S3 (supported in Enterprise Edition only) or Swift. S3 also allows access to Ceph Storage.

Session Storage

  • Redis: provides persistence, nice graphical inspection tools available, supports Nextcloud high-level file locking.
  • If Shibboleth is a requirement you must use Memcached, and it can also be used to scale-out shibd session storage (see Memcache StorageService).
